Fabrication
Formlabs Form 4 3D printer
Stereolithography (SLA) technology
We use this currently to print Engineering Ceramics
Formlabs Form 3 3D printer
Stereolithography (SLA) technology, Materials
We use this to print Polyurethane
Formlabs Form 2 3D printer
Stereolithography (SLA) technology, Materials
This accepts custom resins
Makerbot X 3D printer (Dr. Joshi‘s equipment)
Special materials (in addition to the standard ones)
Carbon Fiber filaments
ULTRAFUSE® 316L Stainless Steel
Stratasys J35 Pro – Multi-Material 3D Printing
Polyjet technology
Elastomers to rigid polymers and intermediate mixtures
Stratasys Origin Two
Digital Light Processing (DLP) printer
Elastomers to rigid polymers
Sinterit Lisa Pro Selective Laser Sintering (SLS) 3D printer
Materials
PA12 (nylon), Polypropylene (PP)
Flexa-grey (TPU, Thermoplastic polyurethane) and others…
Prusa MK3+
FDM 3D Printer
Filament materials
Electric Kiln
Seattle Pottery Supply
Cone 10, 12×9 in
Across International CF1700
Muffle Furnace
Max temp: 1700C, volume: 6in cube
ARE-310 Centrifugal mixer
Thinky Mixer
Trotec Speedy 360
Materials
Acrylic, PFTE, Rubber, Conductive rubber
silver reed sk840
Knitting machine
Zhermack VPS
Polymer fabrication
Characterization
Biaxial testing machine
Machine capable of simultaneous strain along two orthogonal axes. Strains and strain rates are set independently for each axis. Maximum loads of 100N and range of movement 300mm for each axis.
Instron Static testing machine
Accessories
500N load cell
variety of grippers for metal (polymers, elastomers, threads)
Dynamic mechanical analysis (Dr. Ardebili’s Equipment)
Accessories
Shear sandwich, cantilever, and tension grippers
Differential Scanning Calorimeters (Dr. Ardebili’s Equipment)
Accessories
Shear sandwich, cantilever, and tension grippers
Imaging
Nikon Eclipse MA200
DS-Fi3 Microscope Camera
Software
Abaqus Color spectrum – git
This creates several color gradients in Abaqus visualization. The colormaps are taken from Matplotlib. Note that one should never use the default colormap in Abaqus for figures (read more here)
Abaqus Truss / Beam analysis – git
This script takes as input a set of nodal coordinates, connectivities (which also contain the beam information, i.e. E, A, I), boundary conditions and creates an Abaqus model with these defined. The analysis can be set to run automatically.
Matlab truss analysis (linear and nonlinear) (Coming soon)
This Matlab script takes as input a set of nodal coordinates, connectivities (which also contain the beam information, i.e. E, A, I), boundary conditions, calculates the stiffness tensor, and then the deformation vector.
Bar network STL generator (Matlab and python) – git
Instead of using the native mesher for cylindrical bar network, which will create large file sizes, this code takes the set of nodal coordinates, connectivities and area, as well as the polygon count, and outputs a STL file (ascii or binary) with much smaller file size.
Gcode generator for material testing – git
Generating only fill on the x-y plane oriented at a fixed orientation w.r.t. the x axis, replicated in the z direction. The xy pass overlap and the z pass overlap can be controlled independently.
Conformal mapping based microstructure design – git
Calculate the scaling for 3D to 2D shape transformation in Grasshopper. Then overlaying a grid and assigning unit cell microstructure to each grid element.
Chebchev net generator (Coming soon)
Cloth a 3D surface using two groups of orthogonal lines.
